| Optical System |
DIN Optical System, f=160mm, Anti-Mold |
| Viewing Head |
Monocular; Inclined 30° and rotatable 360° |
| Eyepieces |
WF10x/18.5mm field of view, with pointer eyepiece is locked-in to prevent classroom tampering and accept 19mm reticles |
| Nosepiece |
Rear facing, quadruple, ball bearing with positive click stops to ensure parcentration |
| Objectives |
Achromat 4x, 10x, Semi-Plan 40xR* and 100xR oil* – (*spring-loaded). |
| Stage |
Rackless Mechanical Stage; size 150mm x 139mm; travel area 75mm (X) x 32mm (Y) movement with right hand control; vernier scale reading to 0.1mm |
| Condenser |
N.A. 1.25 Abbe condenser on rack and pinion with iris diaphragm and swing-out filter holder |
| Stand |
Cast alloy aluminum; built-in fixed focus stop allows for rapid focusing while protecting specimens; built-in carry handle and cord hanger |
| Illumination |
Variable LED illumination; bulb life rated for 20,000 hours; UL approve |
| Focusing System |
Coaxial coarse and fine focus controls with an adjustable tension control; all metal gears |
| Accessories |
Dust cover, immersion oil and instruction manual included |
| Dimensions (LWH) |
255mm x 198mm x 368mm |
| Warranty |
5-year limited warranty for parts, labor, and electronic components
1-year warranty for LED bulb.
Free Microscope Service Protection |
| Certification |
ISO 9001: 2018 and ISO 14001: 2018; UL approved; CE anti-mold |
